| Type | Details | Descriptions | ||||
| Resolution | 1920*1080 | |||||
| Refresh rate | 60/75Hz | |||||
| Flat/hook | Flag | |||||
| Screen size(Diagonal) | 22 inch | |||||
| Screen ratio | 16:9 | |||||
| Pixel Pitch（mm） | 0.2485(H)×0.244(V) mm | |||||
| Panel type | IPS | |||||
| Picture size | 510(H) x300(V)mm | |||||
| Brightness（cd/m2） | 250±30CD/㎡ | |||||
| Contrast(Typical Value) | 3000:1 | |||||
| Response time (typical value) | 2ms | |||||
| Viewing Angle (typical value) (CR≥10) | 178°(H)/178°(V) | |||||
| Display color | 16.7M | |||||
| Color gamut（sRGB） | 97%sRGB | |||||
| ME | Front rail | ABS，Black, bite flower (silk screen LOGO) | ||||
| Frame | ABS， Black, bite flower | |||||
| Postnotum | SGCC，black spray paint, bite flower | |||||
| Rear cabinet | ABS，Black, bite flower | |||||
| Middle frame | NA | |||||
| Key | ABS，Black, bite flower | |||||
| Pedestal | Aluminum alloy, black paint, bite flower | |||||
| Pillar support | Aluminum alloy, black paint, bite flower | |||||
| Lifting function | NA | |||||
| Pivot | Front 5° Rear 15° (±2°) | |||||
| Swivel | NA | |||||
| Ambient lighting | NA | |||||
| Hanging function | 75mm*75mm | |||||
| Stalinite | NA | |||||
| Carton | Brown paper | |||||
| Host pakaging bag | PE bag | |||||
| OD | YES | |||||
| Dark field balance | YES | |||||
| Other Software Features | Low Blue Light | |||||
| DC dimming | YES | |||||
| Signal interface | VGA*1，HDMI *1 | |||||
| Signal input | VGA，HDMI | |||||
| Audio output | NA | |||||
| Trumpet | NA | |||||
| Adapter | DC 12V （±0.5v） | |||||
| Front light | NA | |||||
| OSD style | TBA | |||||
| Power consumption (working mode) | ≤30W(Typ.) | |||||
| Power consumption (shutdown mode) | 0.5W | |||||
| Attachment | Specification | YES | ||||
| Power line | YES | |||||
| Signal line | HDMI *1M | |||||
| Packing List | Monitor/support/base/adapter/manual /HDMI cable | |||||
| Net weight(kg) | 3Kg (The final material object shall prevail) | |||||
| Gross weight (kg) | 3.5Kg (The final material object shall prevail) | |||||
| Certification | CCC | CCC | ||||
| Energy efficiency | Level 3 | |||||
| Environmental protection | NA | |||||
| Energy saving | NA | |||||
Availability: In Stock
Monitor Narrow Bezel 21.5 inch
2.15 inch 2K 75Hz
SKU: P54985676
